raft and cataraft Frames.

---

Powder Coated: $1,600

The Nimbus 66 is the ultimate raft frame for expedition style trips. It breaks down into a size comparable to a ski bag. It has 2 bays for gear and a foot bar to increase the rower’s leverage. Each oar tower is adjustable in height from 6”-10”.  This is a great feature for the times you land a permit and need to remove the adjustable seat plate and row sitting on the dry box that will sit you a bit higher in the boat.

The Nimbus 66 pairs well with 12’-14’ rafts.

Stock Frame Specs:

• Frame weight 34lbs
• 60” total width
• 66” total length
• Each bay is completely adjustable
• Breaks down into 66”x 13”x6” bundle
• Removable seat plate with 6” of adjustment
• 6”- 10” of height adjustment in oar towers

 Powder Coated: $2,300

The Nimbus 80 is our take on the gear hauler. It has 3 bays for any configuration of gear requirements. It has locations for captain boxes and water jugs to help ease the distribution of weight issue when rigging.

The Nimbus 80 pairs well with 14’-16’ rafts.

Stock Frame Specs:

• Frame weight 53lbs
• 64” Total width
• 80” Total length
• 13” drop
• 40” drop width
• Removeable seat plate with 6” of adjustment
• 6”- 10” adjustable height oar towers

Powder Coated: $2,300

The North Fork frame was designed to address the following key factors: portability, rowing efficiency, and structural integrity. The engineering of the North Fork frame mimics the house truss design. This gives the frame the ability to cascade energy throughout the frame rather than point loading (energy moving to single points). This design helps avoid breakage and increases the longevity of the frame.
Each frame has 6” of adjustment in the seat plate and 3” in the oar towers. Stock Frame Specs:

• Frame weight 38lbs
• 60” total width
• 65” total length
• 38” between tubes
• 21” cockpit
• 15” under rowers’ seat
• 24” back bay
• 9” depth
• 7” tall, removable, and folding oar towers
• (Generally fits a leg inseam of 30-33”)

We carry a large selection of NRS frame parts and have the ability to build you almost any frame that is between 54” and 66” wide or 65” and 88” long. We also carry fishing frame parts, cataraft yokes and other frame accessories. If you are looking for something, reach out. There is a good chance we’ll have it in stock!
